|B||Seat Collar to Center of Rails||180mm||205mm||225mm||255mm|
|D||Min. Insertion Length||125mm||125mm||150mm||180mm|
|E||Full Insertion Length||223mm||248mm||268mm||300mm|
|B||Seat Collar to Center of Rails||170mm|
|D||Min. Insertion Length||120mm|
|E||Full Insertion Length||282mm|
Routing Method: Internal
Diameters: 27.2mm, 30.9mm, 31.6mm, 34.9mm
Travel: 125mm, 150mm, 170mm, 200mm
Stanchion Diameter: 22mm (27.2 diameter), 26mm (30.9 / 31.6 / 34.9 diameter)
Seatpost Material: 7075 Alloy
Lever Compatability: Compatible with all PNW levers and most cable actuated levers from other brands.
Cable and Housing: Cable and housing included only with the purchase of a lever kit
Like most of us, PNW dropper posts need a little TLC to work their best. This service can be done at home, but if you're not feeling that grease stain life, we can take care of it for you. Our service program treats your PNW dropper post for regular wear and tear. Learn More >>>
Using the Dropper without the white nylon Travel Adjust bushing can lead to damage to the dropper and will void the warranty. It is required for the proper function of the post. If your Travel Bushing is damaged, please contact us at firstname.lastname@example.org for a replacement.
Start by checking if your bike is externally or internally routed. The Loam is only compatible for internally routed frames. Second check the seat tube diameter. Want help finding the right dropper for your bike? Click here >>>
This system allows you the maximum drop for your post size. We accomplish this through a notched bushing under the midcap collar so you can dial in a more tailored fit.
As riding frequency and conditions vary, we do not have a strict service interval. Instead, we recommend servicing your post if it starts to feel sticky/slows down. When it does come down to service it is a quick and easy, at home process. Check out our service video's here.
